ServiceNow MCP Server and API Wrapper

What is ServiceNow MCP Server and API Wrapper about?

Enables developers to access and manipulate ServiceNow data through a clean Python interface. It also includes a standalone MCP server that can be deployed for Agentic AI integrations, exposing ServiceNow functionality over HTTP.

How to use ServiceNow MCP Server and API Wrapper?

1. Install the library: python -m pip install servicenow-api
2. Create a client with either OAuth or basic authentication:

import servicenow_api
client = servicenow_api.Api(
    url="https://your-instance.service-now.com",
    username="YOUR_USERNAME",
    password="YOUR_PASSWORD",
    client_id="YOUR_CLIENT_ID",          # optional for OAuth
    client_secret="YOUR_CLIENT_SECRET"   # optional for OAuth
)

3. Call API methods such as client.get_table(table="incident") or use specialized helpers for change management, CI/CD, etc.
4. Run as an MCP server (Docker example):

docker pull knucklessg1/servicenow:latest

Configure compose.yml and mcp.json as shown in the README, then start the container.

Key features of ServiceNow MCP Server and API Wrapper

• Comprehensive API coverage: Application Service, Change Management, CI/CD, CMDB, Import Sets, Incident, Knowledge Base, generic Table access, and custom endpoints.
• Dual authentication: Supports OAuth 2.0 and basic username/password.
• Proxy & SSL verification options for enterprise network environments.
• Response models with easy attribute access (parent.value.nested_value) and model_dump() for dictionary output.
• MCP server mode: Deployable as a Docker container to expose ServiceNow capabilities to AI agents.
• Extensible: When an endpoint is not pre‑implemented, the generic custom request function allows GET/POST/PUT/DELETE on any ServiceNow REST path.

Use cases of ServiceNow MCP Server and API Wrapper

• Automated ticket handling: AI agents can create, update, or resolve incidents directly via the MCP server.
• Change management workflows: Programmatically trigger, approve, or audit change requests.
• CI/CD integration: Retrieve deployment data from ServiceNow and sync with external pipelines.
• Knowledge base queries: Pull articles for AI‑driven support assistants.
• Custom reporting: Extract CMDB or import‑set data for analytics dashboards.

FAQ from the ServiceNow MCP Server and API Wrapper

Q: Do I need a ServiceNow developer instance? A: Yes, a reachable ServiceNow instance with proper API permissions is required.

Q: Which authentication method should I choose? A: OAuth is recommended for production environments; basic auth works for quick tests or on‑prem setups.

Q: Can I extend the wrapper with my own endpoints? A: Absolutely. Use client.custom_request(method, endpoint, data) to call any ServiceNow REST API not covered out‑of‑the‑box.

Q: How do I run the MCP server without Docker? A: The package can be launched via uv run --with servicenow-api servicenow-mcp as indicated in the mcp.json configuration.

Q: What Python versions are supported? A: The library follows typical packaging practices; Python 3.8+ is recommended.

ServiceNow API

Version: 1.3.28

ServiceNow API Python Wrapper

This repository is actively maintained and will continue adding more API calls. It includes a Model Context Protocol (MCP) server for Agentic AI, enhanced with various authentication mechanisms, middleware for observability and control, and optional Eunomia authorization for policy-based access control.

Contributions are welcome!

All API Response objects are customized for the response call. You can access return values in a parent.value.nested_value format, or use parent.model_dump() to get the response as a dictionary.

API Calls:

• Application Service
• Change Management
• CI/CD
• CMDB
• Import Sets
• Incident
• Knowledge Base
• Table
• Custom Endpoint

If your API call isn't supported, you can use the api_request tool to perform GET/POST/PUT/DELETE requests to any ServiceNow endpoint.

Features:

• Authentication: Supports multiple authentication types including none (disabled), static (internal tokens), JWT, OAuth Proxy, OIDC Proxy, and Remote OAuth for external identity providers.
• Middleware: Includes logging, timing, rate limiting, and error handling for robust server operation.
• Eunomia Authorization: Optional policy-based authorization with embedded or remote Eunomia server integration.
• Resources: Provides instance_config and incident_categories for ServiceNow configuration and data.
• Prompts: Includes create_incident_prompt and query_table_prompt for AI-driven interactions.
• OIDC Token Delegation: Supports token exchange for ServiceNow API calls, enabling user-specific authentication via OIDC.
• OpenAPI JSON Tool Import: Import custom ServiceNow API Endpoints through the OpenAPI JSON generated.

MCP CLI

Short Flag	Long Flag	Description
-h	--help	Display help information
-t	--transport	Transport method: 'stdio', 'http', or 'sse' [legacy] (default: stdio)
-s	--host	Host address for HTTP transport (default: 0.0.0.0)
-p	--port	Port number for HTTP transport (default: 8000)
	--auth-type	Authentication type: 'none', 'static', 'jwt', 'oauth-proxy', 'oidc-proxy', 'remote-oauth' (default: none)
	--token-jwks-uri	JWKS URI for JWT verification
	--token-issuer	Issuer for JWT verification
	--token-audience	Audience for JWT verification
	--token-algorithm	JWT signing algorithm (e.g., HS256, RS256). Required for HMAC or static keys. Auto-detected for JWKS.
	--token-secret	Shared secret for HMAC (HS*) verification. Used with --token-algorithm.
	--token-public-key	Path to PEM public key file or inline PEM string for static asymmetric verification.
	--required-scopes	Comma-separated required scopes (e.g., servicenow.read,servicenow.write). Enforced by JWTVerifier.
	--oauth-upstream-auth-endpoint	Upstream authorization endpoint for OAuth Proxy
	--oauth-upstream-token-endpoint	Upstream token endpoint for OAuth Proxy
	--oauth-upstream-client-id	Upstream client ID for OAuth Proxy
	--oauth-upstream-client-secret	Upstream client secret for OAuth Proxy
	--oauth-base-url	Base URL for OAuth Proxy
	--oidc-config-url	OIDC configuration URL
	--oidc-client-id	OIDC client ID
	--oidc-client-secret	OIDC client secret
	--oidc-base-url	Base URL for OIDC Proxy
	--remote-auth-servers	Comma-separated list of authorization servers for Remote OAuth
	--remote-base-url	Base URL for Remote OAuth
	--allowed-client-redirect-uris	Comma-separated list of allowed client redirect URIs
	--eunomia-type	Eunomia authorization type: 'none', 'embedded', 'remote' (default: none)
	--eunomia-policy-file	Policy file for embedded Eunomia (default: mcp_policies.json)
	--eunomia-remote-url	URL for remote Eunomia server
	--enable-delegation	Enable OIDC token delegation to ServiceNow (default: False)
	--servicenow-audience	Audience for the delegated ServiceNow token
	--delegated-scopes	Scopes for the delegated ServiceNow token (space-separated)
	--openapi-file	Path to OpenAPI JSON spec to import tools/resources from
	--openapi-base-url	Base URL for the OpenAPI client (defaults to ServiceNow instance URL)

Using as an MCP Server

The MCP Server can be run in two modes: stdio (for local testing) or http (for networked access). To start the server, use the following commands:

Run in stdio mode (default):

servicenow-mcp --transport "stdio"

Run in HTTP mode:

servicenow-mcp --transport "http"  --host "0.0.0.0"  --port "8000"

Run in Production:

Embedded Eunomia:

mcp_policies.json

{
  "policies": [
    {
      "id": "servicenow_read_policy",
      "description": "Allow read-only tools if user has read scope",
      "allow": true,
      "conditions": [
        {
          "tool": ["get_application", "get_cmdb", "batch_install_result"],  // Per-tool targeting
          "scopes": ["servicenow.read", "servicenow.full"]  // Like your PRODUCT_READ_SCOPE
        }
      ]
    },
    {
      "id": "servicenow_write_policy",
      "description": "Allow write tools if user has write scope and is admin",
      "allow": true,
      "conditions": [
        {
          "tool": ["batch_install", "batch_rollback", "app_repo_install"],  // Write tools
          "scopes": ["servicenow.write", "servicenow.full"],  // Like your PRODUCT_WRITE_SCOPE
          "claims": {"role": "admin"}  // Extra claim check (from JWT)
        }
      ]
    },
    {
      "id": "default_deny",
      "description": "Deny all other access",
      "allow": false
    }
  ]
}

Run command examples:

export IDENTITY_JWKS_URI="https://your-identity-provider.com/.well-known/jwks.json"
export API_IDENTIFIER="servicenow-mcp"
export PRODUCT_READ_SCOPE="mcpserverapi.product.read"
export INVENTORY_READ_SCOPE="mcpserverapi.inventory.read"
servicenow-mcp \
--transport "http"  \
--host "0.0.0.0" \
--port "8000" \
--auth-type "jwt" \
--token-jwks-uri "${IDENTITY_JWKS_URI}" \
--token-issuer "https://your-identity-provider.com" \
--token-audience "${API_IDENTIFIER}" \
--required-scopes "$PRODUCT_READ_SCOPE,$INVENTORY_READ_SCOPE" \
--eunomia-type "embedded" \
--eunomia-policy-file "mcp_policies.json"

# 1. JWKS (Production, RS256)
servicenow-mcp --auth-type jwt \
  --token-jwks-uri https://auth.example.com/.well-known/jwks.json \
  --token-issuer https://auth.example.com \
  --token-audience servicenow-mcp \
  --required-scopes servicenow.read,servicenow.write

# 2. HMAC (Internal, HS256)
servicenow-mcp --auth-type jwt \
  --token-secret "your-256-bit-secret-here-min-32-chars" \
  --token-algorithm HS256 \
  --token-issuer internal-auth \
  --token-audience mcp-api

# 3. Static RSA Key (Dev)
servicenow-mcp --auth-type jwt \
  --token-public-key ./public_key.pem \
  --token-issuer test-issuer \
  --token-audience test-mcp

# 4. With Delegation
--enable-delegation --auth-type jwt ... (uses JWT as subject_token)

#5 JWKS (Production, Asymmetric RS256)
servicenow-mcp --transport "http" --auth-type "jwt" \
  --token-jwks-uri "https://auth.example.com/.well-known/jwks.json" \
  --token-issuer "https://auth.example.com" \
  --token-audience "servicenow-mcp" \
  --required-scopes "servicenow.read,servicenow.write"

#6 HMAC (Internal/Microservices, HS256)
servicenow-mcp --transport "http" --auth-type "jwt" \
  --token-secret "your-256-bit-secret-min-32-chars" \
  --token-algorithm "HS256" \
  --token-issuer "internal-auth" \
  --token-audience "mcp-api"

#7 Static Public Key (Dev/Testing, RS256)
servicenow-mcp --transport "http" --auth-type "jwt" \
  --token-public-key "/path/to/public_key.pem" \
  --token-issuer "test-issuer" \
  --token-audience "test-mcp"

Native Fast MCP Arguments

# Enable JWT verification
export FASTMCP_SERVER_AUTH=fastmcp.server.auth.providers.jwt.JWTVerifier

# For asymmetric verification with JWKS endpoint:
export FASTMCP_SERVER_AUTH_JWT_JWKS_URI="https://auth.company.com/.well-known/jwks.json"
export FASTMCP_SERVER_AUTH_JWT_ISSUER="https://auth.company.com"
export FASTMCP_SERVER_AUTH_JWT_AUDIENCE="mcp-production-api"
export FASTMCP_SERVER_AUTH_JWT_REQUIRED_SCOPES="read:data,write:data"

# OR for symmetric key verification (HMAC):
export FASTMCP_SERVER_AUTH_JWT_PUBLIC_KEY="your-shared-secret-key-minimum-32-chars"
export FASTMCP_SERVER_AUTH_JWT_ALGORITHM="HS256"  # or HS384, HS512
export FASTMCP_SERVER_AUTH_JWT_ISSUER="internal-auth-service"
export FASTMCP_SERVER_AUTH_JWT_AUDIENCE="mcp-internal-api"

Basic API Usage

OAuth Authentication

#!/usr/bin/python
# coding: utf-8
from servicenow_api.servicenow_api import Api

username = "<SERVICENOW USERNAME>"
password = "<SERVICENOW PASSWORD>"
client_id = "<SERVICENOW CLIENT_ID>"
client_secret = "<SERVICENOW_CLIENT_SECRET>"
servicenow_url = "<SERVICENOW_URL>"

client = Api(
    url=servicenow_url,
    username=username,
    password=password,
    client_id=client_id,
    client_secret=client_secret
)

table = client.get_table(table="<TABLE NAME>")
print(f"Table: {table.model_dump()}")

Basic Authentication

#!/usr/bin/python
# coding: utf-8
from servicenow_api.servicenow_api import Api

username = "<SERVICENOW USERNAME>"
password = "<SERVICENOW PASSWORD>"
servicenow_url = "<SERVICENOW_URL>"

client = Api(
    url=servicenow_url,
    username=username,
    password=password
)

table = client.get_table(table="<TABLE NAME>")
print(f"Table: {table.model_dump()}")

Proxy and SSL Verify

#!/usr/bin/python
# coding: utf-8
from servicenow_api.servicenow_api import Api

username = "<SERVICENOW USERNAME>"
password = "<SERVICENOW PASSWORD>"
servicenow_url = "<SERVICENOW_URL>"

proxy = "https://proxy.net"

client = Api(
    url=servicenow_url,
    username=username,
    password=password,
    proxy=proxy,
    verify=False
)

table = client.get_table(table="<TABLE NAME>")
print(f"Table: {table.model_dump()}")

Deploy MCP Server as a Service

The ServiceNow MCP server can be deployed using Docker, with configurable authentication, middleware, and Eunomia authorization.

Using Docker Run

docker pull knucklessg1/servicenow:latest

docker run -d \
  --name servicenow-mcp \
  -p 8004:8004 \
  -e HOST=0.0.0.0 \
  -e PORT=8004 \
  -e TRANSPORT=http \
  -e AUTH_TYPE=none \
  -e EUNOMIA_TYPE=none \
  -e SERVICENOW_INSTANCE=https://yourinstance.servicenow.com \
  -e SERVICENOW_USERNAME=user \
  -e SERVICENOW_PASSWORD=pass \
  -e SERVICENOW_CLIENT_ID=client_id \
  -e SERVICENOW_CLIENT_SECRET=client_secret \
  -e SERVICENOW_VERIFY=False \
  knucklessg1/servicenow:latest

For advanced authentication (e.g., OIDC Proxy with token delegation) or Eunomia, add the relevant environment variables:

For Additional OpenAPI Tool Import, include OPENAPI_FILE.

docker run -d \
  --name servicenow-mcp \
  -p 8004:8004 \
  -e HOST=0.0.0.0 \
  -e PORT=8004 \
  -e TRANSPORT=http \
  -e AUTH_TYPE=oidc-proxy \
  -e FASTMCP_SERVER_AUTH_JWT_ALGORITHM=HS256 \
  -e FASTMCP_SERVER_AUTH_JWT_PUBLIC_KEY="your-shared-secret" \
  -e FASTMCP_SERVER_AUTH_JWT_REQUIRED_SCOPES="servicenow.read,servicenow.write" \
  -e OIDC_CONFIG_URL=https://provider.com/.well-known/openid-configuration \
  -e OIDC_CLIENT_ID=your-client-id \
  -e OIDC_CLIENT_SECRET=your-client-secret \
  -e OIDC_BASE_URL=https://your-server.com \
  -e ALLOWED_CLIENT_REDIRECT_URIS=http://localhost:*,https://*.example.com/* \
  -e ENABLE_DELEGATION=True \
  -e SERVICENOW_AUDIENCE=https://yourinstance.servicenow.com \
  -e DELEGATED_SCOPES="api user_impersonation" \
  -e EUNOMIA_TYPE=embedded \
  -e EUNOMIA_POLICY_FILE=/app/mcp_policies.json \
  -e SERVICENOW_INSTANCE=https://yourinstance.servicenow.com \
  -e SERVICENOW_USERNAME=user \
  -e SERVICENOW_PASSWORD=pass \
  -e SERVICENOW_CLIENT_ID=client_id \
  -e SERVICENOW_CLIENT_SECRET=client_secret \
  -e SERVICENOW_VERIFY=False \
  -e OPENAPI_FILE=/app/servicenow_openapi.json \
  knucklessg1/servicenow:latest

Using Docker Compose

Create a docker-compose.yml file:

services:
  servicenow-mcp:
    image: knucklessg1/servicenow:latest
    environment:
      - HOST=0.0.0.0
      - PORT=8004
      - TRANSPORT=http
      - AUTH_TYPE=none
      - EUNOMIA_TYPE=none
      - SERVICENOW_INSTANCE=https://yourinstance.servicenow.com
      - SERVICENOW_USERNAME=user
      - SERVICENOW_PASSWORD=pass
      - SERVICENOW_CLIENT_ID=client_id
      - SERVICENOW_CLIENT_SECRET=client_secret
      - SERVICENOW_VERIFY=False
    ports:
      - 8004:8004

For advanced setups with authentication, token delegation, and Eunomia:

services:
  servicenow-mcp:
    image: knucklessg1/servicenow:latest
    environment:
      - HOST=0.0.0.0
      - PORT=8004
      - TRANSPORT=http
      - AUTH_TYPE=oidc-proxy
      - OIDC_CONFIG_URL=https://provider.com/.well-known/openid-configuration
      - OIDC_CLIENT_ID=your-client-id
      - OIDC_CLIENT_SECRET=your-client-secret
      - OIDC_BASE_URL=https://your-server.com
      - ALLOWED_CLIENT_REDIRECT_URIS=http://localhost:*,https://*.example.com/*
      - ENABLE_DELEGATION=True
      - SERVICENOW_AUDIENCE=https://yourinstance.servicenow.com
      - DELEGATED_SCOPES='api user_impersonation'
      - EUNOMIA_TYPE=embedded
      - EUNOMIA_POLICY_FILE=/app/mcp_policies.json
      - SERVICENOW_INSTANCE=https://yourinstance.servicenow.com
      - SERVICENOW_USERNAME=user
      - SERVICENOW_PASSWORD=pass
      - SERVICENOW_CLIENT_ID=client_id
      - SERVICENOW_CLIENT_SECRET=client_secret
      - SERVICENOW_VERIFY=False
      - FASTMCP_SERVER_AUTH_JWT_ALGORITHM=HS256
      - FASTMCP_SERVER_AUTH_JWT_PUBLIC_KEY=your-shared-secret
      - FASTMCP_SERVER_AUTH_JWT_REQUIRED_SCOPES=servicenow.read,servicenow.write
    ports:
      - 8004:8004
    volumes:
      - ./mcp_policies.json:/app/mcp_policies.json

Run the service:

docker-compose up -d

Configure mcp.json for AI Integration

Recommended: Store secrets in environment variables with lookup in the JSON file.

For Testing Only: Plain text storage will also work, although not recommended.

{
  "mcpServers": {
    "servicenow": {
      "command": "uv",
      "args": [
        "run",
        "--with",
        "servicenow-api",
        "servicenow-mcp",
        "--transport",
        "${TRANSPORT}",
        "--host",
        "${HOST}",
        "--port",
        "${PORT}",
        "--auth-type",
        "${AUTH_TYPE}",
        "--eunomia-type",
        "${EUNOMIA_TYPE}",
        "--enable-delegation",
        "${ENABLE_DELEGATION}",
        "--servicenow-audience",
        "${SERVICENOW_AUDIENCE}",
        "--delegated-scopes",
        "${DELEGATED_SCOPES}"
      ],
      "env": {
        "SERVICENOW_INSTANCE": "https://yourinstance.servicenow.com",
        "SERVICENOW_USERNAME": "user",
        "SERVICENOW_PASSWORD": "pass",
        "SERVICENOW_CLIENT_ID": "client_id",
        "SERVICENOW_CLIENT_SECRET": "client_secret",
        "SERVICENOW_VERIFY": "False",
        "TOKEN_JWKS_URI": "${TOKEN_JWKS_URI}",
        "TOKEN_ISSUER": "${TOKEN_ISSUER}",
        "TOKEN_AUDIENCE": "${TOKEN_AUDIENCE}",
        "OAUTH_UPSTREAM_AUTH_ENDPOINT": "${OAUTH_UPSTREAM_AUTH_ENDPOINT}",
        "OAUTH_UPSTREAM_TOKEN_ENDPOINT": "${OAUTH_UPSTREAM_TOKEN_ENDPOINT}",
        "OAUTH_UPSTREAM_CLIENT_ID": "${OAUTH_UPSTREAM_CLIENT_ID}",
        "OAUTH_UPSTREAM_CLIENT_SECRET": "${OAUTH_UPSTREAM_CLIENT_SECRET}",
        "OAUTH_BASE_URL": "${OAUTH_BASE_URL}",
        "OIDC_CONFIG_URL": "${OIDC_CONFIG_URL}",
        "OIDC_CLIENT_ID": "${OIDC_CLIENT_ID}",
        "OIDC_CLIENT_SECRET": "${OIDC_CLIENT_SECRET}",
        "OIDC_BASE_URL": "${OIDC_BASE_URL}",
        "REMOTE_AUTH_SERVERS": "${REMOTE_AUTH_SERVERS}",
        "REMOTE_BASE_URL": "${REMOTE_BASE_URL}",
        "ALLOWED_CLIENT_REDIRECT_URIS": "${ALLOWED_CLIENT_REDIRECT_URIS}",
        "EUNOMIA_TYPE": "${EUNOMIA_TYPE}",
        "EUNOMIA_POLICY_FILE": "${EUNOMIA_POLICY_FILE}",
        "EUNOMIA_REMOTE_URL": "${EUNOMIA_REMOTE_URL}",
        "ENABLE_DELEGATION": "${ENABLE_DELEGATION}",
        "SERVICENOW_AUDIENCE": "${SERVICENOW_AUDIENCE}",
        "DELEGATED_SCOPES": "${DELEGATED_SCOPES}"
      },
      "timeout": 200000
    }
  }
}

Middleware

The MCP server includes the following built-in middleware for enhanced functionality:

• ErrorHandlingMiddleware: Provides comprehensive error logging and transformation.
• RateLimitingMiddleware: Limits request frequency with a token bucket algorithm (10 requests/second, burst capacity of 20).
• TimingMiddleware: Tracks execution time of requests.
• LoggingMiddleware: Logs all requests and responses for observability.
• UserTokenMiddleware: Extracts Bearer tokens for OIDC token delegation to ServiceNow (enabled with --enable-delegation).

Eunomia Authorization

The server supports optional Eunomia authorization for policy-based access control:

• Disabled (none): No authorization checks.
• Embedded (embedded): Runs an embedded Eunomia server with a local policy file (mcp_policies.json by default).
• Remote (remote): Connects to an external Eunomia server for centralized policy decisions.

To configure Eunomia policies:

Embedded Eunomia:

mcp_policies.json

{
  "policies": [
    {
      "id": "servicenow_read_policy",
      "description": "Allow read-only tools if user has read scope",
      "allow": true,
      "conditions": [
        {
          "tool": ["get_application", "get_cmdb", "batch_install_result"],  // Per-tool targeting
          "scopes": ["servicenow.read", "servicenow.full"]  // Like your PRODUCT_READ_SCOPE
        }
      ]
    },
    {
      "id": "servicenow_write_policy",
      "description": "Allow write tools if user has write scope and is admin",
      "allow": true,
      "conditions": [
        {
          "tool": ["batch_install", "batch_rollback", "app_repo_install"],  // Write tools
          "scopes": ["servicenow.write", "servicenow.full"],  // Like your PRODUCT_WRITE_SCOPE
          "claims": {"role": "admin"}  // Extra claim check (from JWT)
        }
      ]
    },
    {
      "id": "default_deny",
      "description": "Deny all other access",
      "allow": false
    }
  ]
}

# Initialize a default policy file
eunomia-mcp init

# Validate the policy file
eunomia-mcp validate mcp_policies.json

Install Python Package

python -m pip install servicenow-api eunomia-mcp

python ./test/test_servicenow_models.py
